L0603B3R3MPWFT

Obsolete

KEMET

FIXED IND 3.3UH 130MA SMD

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

L0603B3R3MPWFT

Obsolete

KEMET

FIXED IND 3.3UH 130MA SMD

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	L0603B3R3MPWFT

Current Rating (Amps)	130 mA
Height - Seated (Max) [Max] [z]	0.035 "
Height - Seated (Max) [Max] [z]	0.9 mm
Inductance	3.3 µH
Inductance Frequency - Test	7.96 MHz
Material - Core	Ferrite
Mounting Type	Surface Mount
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Package / Case	0603 (1608 Metric)
Shielding	Unshielded
Size / Dimension [x]	0.063 in
Size / Dimension [x]	1.6 mm
Size / Dimension [y]	0.8 mm
Size / Dimension [y]	0.031 in
Supplier Device Package	1608 Metric
Supplier Device Package	0603
Tolerance	20 %
Type	Wirewound, Drum Core

L0603B Series

Part	Inductance	Current Rating (Amps)	Mounting Type	Frequency - Self Resonant	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Tolerance	Material - Core	Package / Case	Shielding	Supplier Device Package	Supplier Device Package	Inductance Frequency - Test	DC Resistance (DCR)	Type	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KEMET L0603B220MDWFT	22 µH	0.23 A	Surface Mount	16 MHz	0.8 mm	0.063 in	1.6 mm	0.031 in	0.039 "	1 mm	20 %	Ferrite	0603 (1608 Metric)	Unshielded	1608 Metric	0603	2.52 MHz	1 Ohm	Drum Core Wirewound	-40 °C	105 ░C
KEMET L0603B2R2MPWFT	2.2 µH	430 mA	Surface Mount		0.8 mm	0.063 in	1.6 mm	0.031 in			20 %	Ferrite	0603 (1608 Metric)	Unshielded	1608 Metric	0603	7.96 MHz	330 mOhm	Drum Core Wirewound	-40 °C	105 ░C	0.035 "	0.9 mm
KEMET L0603B3R3MDWFT	3.3 µH		Surface Mount		0.8 mm	0.063 in	1.6 mm	0.031 in	0.039 "	1 mm	20 %	Ferrite	0603 (1608 Metric)	Unshielded	1608 Metric	0603			Drum Core Wirewound	-40 °C	105 ░C
KEMET L0603B100KPWFT	10 µH	0.2 A	Surface Mount	40 MHz	0.8 mm	0.063 in	1.6 mm	0.031 in			10 %	Ferrite	0603 (1608 Metric)	Unshielded	1608 Metric	0603	2.52 MHz	1.2 Ohm	Drum Core Wirewound	-40 °C	105 ░C	0.035 "	0.9 mm
KEMET L0603B3R3MPWFT	3.3 µH	130 mA	Surface Mount		0.8 mm	0.063 in	1.6 mm	0.031 in			20 %	Ferrite	0603 (1608 Metric)	Unshielded	1608 Metric	0603	7.96 MHz		Drum Core Wirewound	-40 °C	105 ░C	0.035 "	0.9 mm
KEMET L0603B220KDWFT	22 µH	0.23 A	Surface Mount	16 MHz	0.8 mm	0.063 in	1.6 mm	0.031 in	0.039 "	1 mm	10 %	Ferrite	0603 (1608 Metric)	Unshielded	1608 Metric	0603	2.52 MHz	1 Ohm	Drum Core Wirewound	-40 °C	105 ░C

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 0.34
		10	$ 0.27
		25	$ 0.25
		50	$ 0.23
		100	$ 0.20
		250	$ 0.20
		500	$ 0.18
		1000	$ 0.14

Description

General part information

L0603B Series

3.3 µH Unshielded Drum Core, Wirewound Inductor 130 mA 0603 (1608 Metric)
