MVA100015A

Active

Inventus Power

AC/DC CONVERTER 15V 100W

Search across all available documentation for this part.

Active

Inventus Power

AC/DC CONVERTER 15V 100W

Technical Specifications

Parameters and characteristics for this part

AC/DC CONVERTER 15V 100W

Part	Type	Voltage - Output 1	Applications	Approval Agency	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Efficiency	Operating Temperature [Min]	Operating Temperature [Max]	Power (Watts)	Mounting Type	Number of Outputs	Current - Output 1	Features	Minimum Load Required
Inventus Power MVA100015A	Open Frame	15 V	Medical	CB, CE, cTUVus	114.3 mm	28.5 mm	2.5 in	1.1 in	63.1 mm	4.5 in	90 %	-20 °C	70 °C	100 W, 120 W	Chassis Mount	1	6.7 A	Universal Input

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 64.38

General part information

Open Frame AC DC Converters 1 Output 15V 85 ~ 264 VAC Input

Technical documentation and resources

No documents available
