MTC0528S3V3
ActiveXP POWER
DC DC CONVERTER 3.3V 5W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MTC0528S3V3
ActiveXP POWER
DC DC CONVERTER 3.3V 5W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MTC0528S3V3 |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 1.21 A |
| Efficiency | 80 % |
| Features | OVP, OCP, OTP |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 12-DIP Module, 9 Leads |
| Power (Watts) | 5 W |
| Size / Dimension [x] | 32 mm |
| Size / Dimension [x] | 1.26 in |
| Size / Dimension [y] | 0.76 in |
| Size / Dimension [y] | 19.3 mm |
| Size / Dimension [z] | 8.7 mm |
| Size / Dimension [z] | 0.34 in |
| Type | Isolated Module |
| Voltage - Input (Min) [Min] | 15.5 V |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 3.3 V |
MTC0528 Series
| Part | Type | Number of Outputs | Current - Output (Max) [Max] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Applications | Mounting Type | Package / Case | Voltage - Output 1 | Power (Watts) | Efficiency | Voltage - Input (Min) [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Features | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
XP POWER | Isolated Module | 1 | 1.21 A | 0.76 in | 32 mm | 8.7 mm | 1.26 in | 0.34 in | 19.3 mm | ITE (Commercial) | Through Hole | 12-DIP Module 9 Leads | 3.3 V | 5 W | 80 % | 15.5 V | 100 °C | -40 °C | OCP OTP OVP | 1.5 kV |
XP POWER | Isolated Module | 1 | 800 mA | 0.76 in | 32 mm | 8.7 mm | 1.26 in | 0.34 in | 19.3 mm | ITE (Commercial) | Through Hole | 12-DIP Module 9 Leads | 5 V | 5 W | 77 % | 15.5 V | 100 °C | -40 °C | OCP OTP OVP | 1.5 kV |
XP POWER | Isolated Module | 1 | 180 mA | 0.76 in | 32 mm | 8.7 mm | 1.26 in | 0.34 in | 19.3 mm | ITE (Commercial) | Through Hole | 12-DIP Module 9 Leads | 28 V | 5 W | 78 % | 15.5 V | 100 °C | -40 °C | OCP OTP OVP | 1.5 kV |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 50 | $ 191.73 | |
Description
General part information
MTC0528 Series
Isolated Module DC DC Converter 1 Output 3.3V 1.21A 15.5V - 40V Input
