TDP-120-A-K-A-300

Active

ATC-Diversified Electronics

RELAY TIME DELAY 300SEC 10A 250V

Search across all available documentation for this part.

Active

ATC-Diversified Electronics

RELAY TIME DELAY 300SEC 10A 250V

Technical Specifications

Parameters and characteristics for this part

RELAY TIME DELAY 300SEC 10A 250V

Part	Function	Relay Type	Timing Adjustment Method	Contact Rating @ Voltage	Voltage - Supply	Delay Time [Min]	Delay Time [Max]	Mounting Type	Termination Style	Timing Initiate Method	Circuit
ATC-Diversified Electronics TDP-120-A-K-A-300	Repeat Cycle	Mechanical Relay	Hand Dial	10 A	120 VAC	3 Sec	300 Sec	Socketable	Plug In, 8 Pin (Octal)	Input Voltage	DPDT (2 Form C)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Repeat Cycle Time Delay Relay DPDT (2 Form C) 3 Sec ~ 300 Sec Delay 10A @ 250VAC/24VDC Socketable
