Part	Contact Material	Contact Finish	Wire Gauge	Contact Termination	Pin or Socket	Type	Contact Finish Thickness	Contact Finish Thickness (string set options)	Contact Finish Thickness	Contact Type	Features	Wire Gauge or Range - AWG
ITT Cannon, LLC T3P20FF1LT	Brass	Tin	20 AWG	Solder	Socket	Machined
ITT Cannon, LLC T3P20MW2LZ	Brass	Gold	20 AWG	Wire Wrap	Pin	Machined	0	Flash	Flash
ITT Cannon, LLC T3P20MF11LT	Brass	Tin	20 AWG	Solder	Pin	Machined
ITT Cannon, LLC T3P20FC3LT	Brass	Tin	20 AWG	Crimp	Socket	Machined
ITT Cannon, LLC T3P20FW2LZ	Brass	Gold	20 AWG	Wire Wrap	Socket	Machined	0	Flash	Flash
ITT Cannon, LLC T3P20MC1LY	Brass	Gold	20 AWG	Crimp	Pin	Machined	15 µin
ITT Cannon, LLC T3P20FC1LT	Brass	Tin	20 AWG	Crimp	Socket	Machined
ITT Cannon, LLC T3P20FC3LZ	Brass	Gold	20 AWG	Crimp	Socket	Machined	0	Flash	Flash
ITT Cannon, LLC T3P20FF1LY	Brass	Gold	20 AWG	Solder	Socket	Machined	15 µin
ITT Cannon, LLC T3P20FE1LY	Brass	Gold		Crimp		Signal Stamped	29.5 µin			Earth Socket	Insulation Support	20 AWG

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Technical documentation and resources
