KU-11A35-24
ActiveTE Connectivity Potter & Brumfield Relays
RELAY GEN PURPOSE DPDT 10A 24V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | KU-11A35-24 |
|---|---|
| Approval Agency | CSA, UR |
| Coil Current | 84 mA |
| Coil Insulation | Class B |
| Coil Type | Non Latching |
| Coil Voltage | 24 VAC |
| Contact Form | DPDT (2 Form C) |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Contact Rating (Current) | 10 A |
| Mounting Type | Chassis Mount |
| Operate Time | 15 ms |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -45 °C |
| Relay Type | General Purpose |
| Release Time | 10 ms |
| Switching Voltage | 240 VAC |
| Termination Style | Quick Connect - 0.187" (4.7mm) |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 150 | $ 32.42 | |
Description
General part information
KU-11A Series
General Purpose Relay DPDT (2 Form C) 24VAC Coil Chassis Mount
