FLBB-03EGFS-GCP-001

Active

Amphenol LTW

FLOS, B SERIES B SIZE, 8A, 03 PI

Search across all available documentation for this part.

Active

Amphenol LTW

FLOS, B SERIES B SIZE, 8A, 03 PI

Technical Specifications

Parameters and characteristics for this part

Specification	FLBB-03EGFS-GCP-001

Applications	Testing Equipment & Measurement, Medical, Industrial, Telecommunications, Instrumentation
Color	Silver
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	8 A
Fastening Type	Push-Pull
Ingress Protection	IP50
Mounting Feature	Bulkhead - Rear Side Nut
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Orientation	G
Primary Material	Metal
Shell Material	Metal
Shell Size - Insert	B-3
Shielding	Shielded
Voltage Rating	400 V

Part	Contact Finish - Mating	Mounting Feature	Applications	Contact Material	Shielding	Primary Material	Fastening Type	Ingress Protection	Shell Material	Orientation	Current Rating (Amps)	Voltage Rating	Shell Size - Insert	Connector Type	Operating Temperature [Max]	Operating Temperature [Min]	Color
Amphenol LTW FLBB-03EGFS-GCP-001	Gold	Bulkhead - Rear Side Nut	Industrial Instrumentation Medical Telecommunications Testing Equipment & Measurement	Copper Alloy	Shielded	Metal	Push-Pull	IP50	Metal	G	8 A	400 V	B-3	Receptacle Female Sockets	125 °C	-40 °C	Silver

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 11.67

General part information

3 Position Circular Connector Receptacle, Female Sockets Solder Cup

Technical documentation and resources

No documents available
