ATO_35A

0287004.PXCN

Active
LITTELFUSE

AUTOMOTIVE FUSES ATOF 32V 4A LOW-CURRENT NYLON

Find alt
ATO_35A

0287004.PXCN

Active
LITTELFUSE

AUTOMOTIVE FUSES ATOF 32V 4A LOW-CURRENT NYLON

Find alt

Description

General part information

287 Series

This 4 A ATOF® 32V automotive blade fuses replaced an obsolete ATO Series 257 fuse with the same ampere rating. Automakers around the world consider ATOF fuses standard equipment for protecting low-voltage circuits.

Technical Specifications

Parameters and characteristics for this part

Specification0287004.PXCN
Approval AgencyUL
Breaking Capacity1 kA
ColorPink
Current Rating4 A
Fuse TypeAutomotive
Melting I²t14
Mounting TypeRequires Holder
Operating Temperature (Max)105 °C
Operating Temperature (Min)-40 °C
Package / CaseATO/ATC, Blade
Response TimeFast Blow
Size / Dimension Height0.484 in
Size / Dimension Length0.752 in
Size / Dimension Width0.201 in
Voltage Rating - DC32 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Sign in to see pricing

Create a free account to access distributor pricing data.

Sign up — freeLog in

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

Datasheet
0287004.PXCN | Datasheet
