M20-9771146

Active

Harwin Inc.

11 POS. MALE SIL VERTICAL THROUGHBOARD CONN. ROHS COMPLIANT: YES

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet M20 Series Spec Sheet +1

M20-9771146

Active

Harwin Inc.

11 POS. MALE SIL VERTICAL THROUGHBOARD CONN. ROHS COMPLIANT: YES

Deep-Dive with AI

DocumentsDatasheet M20 Series Spec Sheet +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	M20-9771146

Connector Type	Cuttable, Header
Contact Finish - Post	Tin
Contact Length - Mating	0.228 in
Contact Length - Mating	5.8 mm
Contact Length - Post	0.122 "
Contact Length - Post	3.1 mm
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	3 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.1 in
Insulation Height	2.54 mm
Insulation Material	Nylon 6T, Polyamide (PA6T)
Mated Stacking Heights	16.54 mm, 10.04 mm, 10.64 mm, 11.04 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	11
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Overall Contact Length	0.452 "
Overall Contact Length	11.48 mm
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Shrouding	Unshrouded
Style	Board to Board, Cable
Termination	Solder

M20-977 Series

Part	Insulation Height	Insulation Height	Shrouding	Overall Contact Length	Overall Contact Length	Insulation Material	Termination	Contact Finish - Mating	Insulation Color	Current Rating (Amps)	Contact Length - Post	Contact Length - Post	Contact Length - Mating	Contact Length - Mating	Connector Type	Fastening Type	Mated Stacking Heights	Mounting Type	Contact Material	Number of Positions Loaded	Style	Number of Rows	Contact Type	Material Flammability Rating	Contact Shape	Contact Finish - Post	Pitch - Mating	Pitch - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions	Number of Positions
Harwin Inc. M20-9770542	0.1 in	2.54 mm	Unshrouded	0.452 "	11.48 mm	Nylon 6T Polyamide (PA6T)	Solder	Gold	Black	3 A	0.122 "	3.1 mm	0.228 in	5.8 mm	Cuttable Header	Push-Pull	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Through Hole	Brass	All	Board to Board Cable	1	Male Pin	UL94 V-0	Square	Tin	0.1 in	2.54 mm	-40 °C	105 ░C
Harwin Inc. M20-9772646	0.1 in	2.54 mm	Unshrouded	0.452 "	11.48 mm	Nylon 6T Polyamide (PA6T)	Solder		Black	3 A	0.122 "	3.1 mm	0.228 in	5.8 mm	Cuttable Header	Push-Pull	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Through Hole	Brass	All	Board to Board Cable	1	Male Pin	UL94 V-0	Square	Tin	0.1 in	2.54 mm	-40 °C	105 ░C	26
Harwin Inc. M20-9771646	0.1 in	2.54 mm	Unshrouded	0.452 "	11.48 mm	Nylon 6T Polyamide (PA6T)	Solder		Black	3 A	0.122 "	3.1 mm	0.228 in	5.8 mm	Cuttable Header	Push-Pull	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Through Hole	Brass	All	Board to Board Cable	1	Male Pin	UL94 V-0	Square	Tin	0.1 in	2.54 mm	-40 °C	105 ░C		16
Harwin Inc. M20-9771846	0.1 in	2.54 mm	Unshrouded	0.452 "	11.48 mm	Nylon 6T Polyamide (PA6T)	Solder		Black	3 A	0.122 "	3.1 mm	0.228 in	5.8 mm	Cuttable Header	Push-Pull	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Through Hole	Brass	All	Board to Board Cable	1	Male Pin	UL94 V-0	Square	Tin	0.1 in	2.54 mm	-40 °C	105 ░C	18
Harwin Inc. M20-9770946	0.1 in	2.54 mm	Unshrouded	0.452 "	11.48 mm	Nylon 6T Polyamide (PA6T)	Solder		Black	3 A	0.122 "	3.1 mm	0.228 in	5.8 mm	Cuttable Header	Push-Pull	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Through Hole	Brass	All	Board to Board Cable	1	Male Pin	UL94 V-0	Square	Tin	0.1 in	2.54 mm	-40 °C	105 ░C	9
Harwin Inc. M20-9773246	0.1 in	2.54 mm	Unshrouded	0.452 "	11.48 mm	Nylon 6T Polyamide (PA6T)	Solder		Black	3 A	0.122 "	3.1 mm	0.228 in	5.8 mm	Cuttable Header	Push-Pull	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Through Hole	Brass	All	Board to Board Cable	1	Male Pin	UL94 V-0	Square	Tin	0.1 in	2.54 mm	-40 °C	105 ░C
Harwin Inc. M20-9770842	0.1 in	2.54 mm	Unshrouded	0.452 "	11.48 mm	Nylon 6T Polyamide (PA6T)	Solder	Gold	Black	3 A	0.122 "	3.1 mm	0.228 in	5.8 mm	Cuttable Header	Push-Pull	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Through Hole	Brass	All	Board to Board Cable	1	Male Pin	UL94 V-0	Square	Tin	0.1 in	2.54 mm	-40 °C	105 ░C	8
Harwin Inc. M20-9770242	0.1 in	2.54 mm	Unshrouded	0.452 "	11.48 mm	Nylon 6T Polyamide (PA6T)	Solder	Gold	Black	3 A	0.122 "	3.1 mm	0.228 in	5.8 mm	Cuttable Header	Push-Pull	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Through Hole	Brass	All	Board to Board Cable	1	Male Pin	UL94 V-0	Square	Tin	0.1 in	2.54 mm	-40 °C	105 ░C	2
Harwin Inc. M20-9771146	0.1 in	2.54 mm	Unshrouded	0.452 "	11.48 mm	Nylon 6T Polyamide (PA6T)	Solder		Black	3 A	0.122 "	3.1 mm	0.228 in	5.8 mm	Cuttable Header	Push-Pull	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Through Hole	Brass	All	Board to Board Cable	1	Male Pin	UL94 V-0	Square	Tin	0.1 in	2.54 mm	-40 °C	105 ░C	11
Harwin Inc. M20-9771246	0.1 in	2.54 mm	Unshrouded	0.452 "	11.48 mm	Nylon 6T Polyamide (PA6T)	Solder		Black	3 A	0.122 "	3.1 mm	0.228 in	5.8 mm	Cuttable Header	Push-Pull	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Through Hole	Brass	All	Board to Board Cable	1	Male Pin	UL94 V-0	Square	Tin	0.1 in	2.54 mm	-40 °C	105 ░C	12
