PBFS19008BK2
ObsoleteHammond Manufacturing
GLOSS BLACK FORMED STEEL RACK PANELS PBFS SERIES
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsPBFS19001 Drawing

PBFS19008BK2
ObsoleteHammond Manufacturing
GLOSS BLACK FORMED STEEL RACK PANELS PBFS SERIES
Deep-Dive with AI
DocumentsPBFS19001 Drawing
Technical Specifications
Parameters and characteristics for this part
| Specification | PBFS19008BK2 |
|---|---|
| Color | Black |
| For Use With/Related Products | 19" Panel Width Racks |
| Material | Metal, Steel |
| Size / Dimension [x] | 19 " |
| Size / Dimension [x] | 482.6 mm |
| Size / Dimension [y] | 221.49 mm |
| Size / Dimension [y] | 8.72 in |
| Size / Dimension [z] | 0.5 in |
| Size / Dimension [z] | 12.7 mm |
| Type | Panel, Front |
| Ventilation | Non-Vented |
| Weight | 3 lb |
| Weight | 1.4 kg |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 35.67 | |
| 5 | $ 30.49 | |||
| 10 | $ 28.50 | |||
| 25 | $ 26.06 | |||
| 50 | $ 24.75 | |||
Description
General part information
PBFS19008 Series
Metal, Steel Panel, Front 19.000" L x 8.720" W x 0.500" H (482.60mm x 221.49mm x 12.70mm) Black
