MA256.A.LBI.001

Active

TAOGLAS

COMBO ANTENNA, 2.49-2.69GHZ, -1.8DBI ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

TAOGLAS

COMBO ANTENNA, 2.49-2.69GHZ, -1.8DBI ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	MA256.A.LBI.001

Antenna Type	Module
Applications	GLONASS, GPS, Beidou, LTE
Features	Filter, Cable - 2m, LNA
Frequency (Center/Band)	752 MHz, 1.561 GHz, 1.575 GHz, 2.59 GHz, 1.4725 GHz, 657.5 MHz, 1.955 GHz, 1.602 GHz, 892 MHz
Frequency Group	Wide Band
Gain	-1 dBi, -2.3 dBi, -3.9 dBi, -1.8 dBi, -3.1 dBi
Height (Max) [Max]	12 mm
Height (Max) [Max]	0.472 in
Ingress Protection	IP67
Mounting Type	Adhesive
Number of Bands	9
Power - Max [Max]	2 W
RF Family/Standard	Cellular, Navigation
VSWR	2, 3

Part	Antenna Type	Mounting Type	Gain	Frequency Group	Ingress Protection	Frequency (Center/Band)	Applications	VSWR	Number of Bands	Height (Max) [Max]	Height (Max) [Max]	RF Family/Standard	Features	Power - Max [Max]
TAOGLAS MA256.A.LBI.001	Module	Adhesive	-3.9 dBi -3.1 dBi -2.3 dBi -1.8 dBi -1 dBi	Wide Band	IP67	1.4725 GHz 1.561 GHz 1.575 GHz 1.602 GHz 1.955 GHz 2.59 GHz 657.5 MHz 752 MHz 892 MHz	Beidou GLONASS GPS LTE	2 3	9	12 mm	0.472 in	Cellular Navigation	Cable - 2m Filter LNA	2 W

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RF ANTENNA BEIDOU, GLONASS, GPS, LTE Module SMA Male Adhesive
