SRP1235-R33M

Obsolete

Bourns Inc.

FIXED IND 330NH 36.5A 1.5MOHM SM

Search across all available documentation for this part.

Obsolete

Bourns Inc.

FIXED IND 330NH 36.5A 1.5MOHM SM

Technical Specifications

Parameters and characteristics for this part

Part	Operating Temperature [Min]	Operating Temperature [Max]	Current - Saturation (Isat)	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Tolerance	Mounting Type	DC Resistance (DCR) [Max]	Inductance	Material - Core	Shielding	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Frequency - Self Resonant	Package / Case	Current Rating (Amps)	Inductance Frequency - Test	DC Resistance (DCR)
Bourns Inc. SRP1235-R68M	-55 °C	150 °C	40 A	0.547 in	13.9 mm	0.531 in	13.5 mm	20 %	Surface Mount	2.5 mOhm	0.68 µH	Iron	Shielded	0.146 in	3.7 mm	72 MHz	Nonstandard	28 A	100 kHz
Bourns Inc. SRP1235-R22M	-55 °C	150 °C	50 A	0.547 in	13.9 mm	0.531 in	13.5 mm	20 %	Surface Mount	1.3 mOhm	220 nH	Iron	Shielded	0.146 in	3.7 mm	94 MHz	Nonstandard	38.5 A	100 kHz
Bourns Inc. SRP1235-R60M	-55 °C	150 °C	42 A	0.547 in	13.9 mm	0.531 in	13.5 mm	20 %	Surface Mount	2.5 mOhm	600 nH	Iron	Shielded	0.146 in	3.7 mm	73 MHz	Nonstandard	29 A	100 kHz
Bourns Inc. SRP1235-R33M	-55 °C	150 °C	50 A	0.547 in	13.9 mm	0.531 in	13.5 mm	20 %	Surface Mount		330 nH	Iron	Shielded	0.146 in	3.7 mm	90 MHz	Nonstandard	36.5 A	100 kHz	1.5 mOhm
Bourns Inc. SRP1235-1R5M	-55 °C	150 °C	28 A	0.547 in	13.9 mm	0.531 in	13.5 mm	20 %	Surface Mount	5.5 mOhm	1.5 µH	Iron	Shielded	0.146 in	3.7 mm	37 MHz	Nonstandard	19 A	100 kHz

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

330 nH Shielded Inductor 36.5 A 1.5mOhm Max Nonstandard
