M80-5752605 - M80-5750605

M80-5752605

Active
Harwin Inc.

RECTANGULAR CONNECTOR, DATAMATE J-TEK M80 SERIES, 26 CONTACTS, PLUG, 2 MM, CRIMP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsM80-001Datasheet+5
M80-5752605 - M80-5750605

M80-5752605

Active
Harwin Inc.

RECTANGULAR CONNECTOR, DATAMATE J-TEK M80 SERIES, 26 CONTACTS, PLUG, 2 MM, CRIMP

Deep-Dive with AI

DocumentsM80-001Datasheet+5

Technical Specifications

Parameters and characteristics for this part

SpecificationM80-5752605
Cable TerminationCrimp
ColorBlack
Connector TypeHeader
Contact FinishGold
Contact Finish Thickness10 Áin
Contact Finish Thickness0.25 Ám
Contact TypeMale Pin
Mounting TypeFree Hanging (In-Line)
Number of Positions26
Number of Rows2
Pitch [x]0.079 in
Pitch [x]2 mm
Row Spacing2 mm
Row Spacing0.079 in
Wire Gauge22 AWG
Wire TypeDiscrete

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 50$ 13.12
NewarkEach 10$ 15.59
50$ 14.06
100$ 13.30
250$ 12.15
500$ 11.31
1000$ 10.39
2500$ 10.16

Description

General part information

M80-575 Series

26 Position Rectangular Header Connector Crimp Gold 22 AWG
