BDU-08RMFS-LC7001

Active

Amphenol LTW

CERES, STANDARD SIZE, 5A+2A, 08

Search across all available documentation for this part.

Active

Amphenol LTW

CERES, STANDARD SIZE, 5A+2A, 08

Technical Specifications

Parameters and characteristics for this part

Specification	BDU-08RMFS-LC7001

Color	Black
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	5 A, 2 A
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Bulkhead - Front Side Nut
Number of Positions	8
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	B
Shielding	Unshielded
Voltage Rating	250 VDC

Part	Contact Material	Ingress Protection	Voltage Rating	Contact Finish - Mating	Shielding	Current Rating (Amps)	Insert Material	Connector Type	Primary Material	Orientation	Color	Mounting Feature	Number of Positions	Operating Temperature [Min]	Operating Temperature [Max]	Shell Size - Insert	Shell Material
Amphenol LTW BDU-08RMFS-SC7001	Copper Alloy	IP67 - Dust Tight Waterproof	250 VDC	Gold	Unshielded	2 A 5 A	Polyamide (PA) Nylon Glass Filled	Receptacle Female Sockets	Plastic	Keyed	Black	Bulkhead - Front Side Nut	8	-40 °C	105 ░C	B	Glass Filled Nylon Polyamide (PA)
Amphenol LTW BDU-08RMFS-LC7001	Copper Alloy	IP67 - Dust Tight Waterproof	250 VDC	Gold	Unshielded	2 A 5 A	Polyamide (PA) Nylon Glass Filled	Receptacle Female Sockets	Plastic	Keyed	Black	Bulkhead - Front Side Nut	8	-40 °C	105 ░C	B	Glass Filled Nylon Polyamide (PA)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

8 Position Circular Connector Receptacle, Female Sockets Solder Cup
