Specification	R191424000

Adapter Series	BNC to N
Adapter Type	Jack to Jack
Body Finish	Nickel
Body Material	Brass
Center Contact Material	Beryllium Copper
Center Contact Plating	Gold
Center Gender	Female
Conversion Type	Between Series
Convert From (Adapter End)	BNC Jack, Female Socket
Convert To (Adapter End) Gender	Female Socket
Convert To (Adapter End) Type	N Jack
Dielectric Material	Polytetrafluoroethylene (PTFE)
Fastening Type	Threaded, Bayonet Lock
Frequency - Max	4 GHz
Impedance	50 Ohm
Mounting Feature	Flange
Mounting Type	Panel Mount
Operating Temperature (Max)	165 °C
Operating Temperature (Min)	-65 °C
Style	Straight

R19142 Series

Part	Dielectric Material	Operating Temperature (Max)	Operating Temperature (Min)	Body Finish	Center Contact Material	Body Material	Impedance	Fastening Type	Frequency - Max	Style	Mounting Type	Center Contact Plating	Adapter Type	Adapter Series	Convert To (Adapter End) Type	Convert To (Adapter End) Gender	Convert From (Adapter End)	Center Gender	Conversion Type	Mounting Feature	Mating Cycles
Radiall USA, Inc. R191421000	Polytetrafluoroethylene (PTFE)	125 °C	-65 °C	Nickel	Beryllium Copper	Brass	50 Ohm	Bayonet Lock Threaded	4 GHz	Straight	Free Hanging (In-Line)	Gold	Plug to Jack	BNC to N	N Plug	Male Pin	BNC Jack Female Socket	Female Male	Between Series
Radiall USA, Inc. R191424000	Polytetrafluoroethylene (PTFE)	165 °C	-65 °C	Nickel	Beryllium Copper	Brass	50 Ohm	Bayonet Lock Threaded	4 GHz	Straight	Panel Mount	Gold	Jack to Jack	BNC to N	N Jack	Female Socket	BNC Jack Female Socket	Female	Between Series	Flange
Radiall USA, Inc. R191429000	Polytetrafluoroethylene (PTFE)	125 °C	-55 °C	Nickel	Beryllium Copper	Brass	50 Ohm	Bayonet Lock	4 GHz	Straight	Free Hanging (In-Line)		Jack to Jack	BNC to C	C Jack	Male Pin	BNC Jack Female Socket	Female Male	Between Series		500 cycles
