ZUW252412-G

Active

Cosel USA, Inc.

DC DC CONVERTER +/-12V 24V 25W

Search across all available documentation for this part.

Active

Cosel USA, Inc.

DC DC CONVERTER +/-12V 24V 25W

Technical Specifications

Parameters and characteristics for this part

DC DC CONVERTER +/-12V 24V 25W

Part	Power (Watts)	Mounting Type	Package / Case	Voltage - Output 2	Type	Efficiency	Number of Outputs	Applications	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Isolation	Voltage - Output 1	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Voltage - Input (Min) [Min]	Current - Output (Max)	Voltage - Input (Max) [Max]
Cosel USA, Inc. ZUW252412-G	25 W	Through Hole	7-DIP Module	-12 V	Isolated Module	85 %	2	ITE (Commercial)	-20 °C	71 °C	500 V	12 V	65 mm	2.56 in	0.33 in	1.97 "	8.5 mm	50 mm	18 V	1.05 A	36 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 85.39

General part information

Isolated Module DC DC Converter 2 Output 12V -12V 1.05A, 1.05A 18V - 36V Input
