PSA241.5-9IRG

Active

Bel Power Solutions

DC DC CONVERTER 24V

Search across all available documentation for this part.

Active

Bel Power Solutions

DC DC CONVERTER 24V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Non-Isolated PoL Module, Conformal Coated DC DC Converter 1 Output 24V 1.5A 31V - 144V Input

Technical documentation and resources

No documents available

Specification	PSA241.5-9IRG	PSA241.5 Series

Applications	Railway, ITE (Commercial)	Railway, ITE (Commercial)
Current - Output (Max) [Max]	1.5 A	1.5 A
Efficiency	93 %	93 %
Features	UVLO, Remote On/Off, SCP	UVLO, Remote On/Off, SCP
Mounting Type	Through Hole	Through Hole
Number of Outputs	1	1
Operating Temperature [Max]	71 °C	71 °C
Operating Temperature [Min]	-40 °C	-40 - -25 °C
Package / Case	Module	6-DIP Module, Module
Type	Non-Isolated PoL Module, Conformal Coated	Non-Isolated PoL Module, Conformal Coated
Voltage - Input (Max) [Max]	144 V	144 V
Voltage - Input (Min) [Min]	31 V	31 V
Voltage - Output 1	24 V	24 V

Part	Type	Current - Output (Max) [Max]	Voltage - Input (Max) [Max]	Applications	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Voltage - Output 1	Efficiency	Voltage - Input (Min) [Min]	Number of Outputs	Package / Case	Features
Bel Power Solutions PSA241.5-9IRY	Conformal Coated, Non-Isolated PoL Module	1.5 A	144 V	ITE (Commercial), Railway	-40 °C	71 °C	Through Hole	24 V	93 %	31 V	1	6-DIP Module
Bel Power Solutions PSA241.5-9IRG	Conformal Coated, Non-Isolated PoL Module	1.5 A	144 V	ITE (Commercial), Railway	-40 °C	71 °C	Through Hole	24 V	93 %	31 V	1	Module	Remote On/Off, SCP, UVLO
Bel Power Solutions PSA241.5-7IRY	Conformal Coated, Non-Isolated PoL Module	1.5 A	144 V	ITE (Commercial), Railway	-25 °C	71 °C	Through Hole	24 V	93 %	31 V	1	6-DIP Module
