RFAA4240J240J
ActiveBULGIN LIMITED
RF / COAXIAL ADAPTER, 2.4MM COAXIAL, JACK, 2.4MM COAXIAL, JACK, STRAIGHT PANEL ADAPTER, 50 OHM
RFAA4240J240J
ActiveBULGIN LIMITED
RF / COAXIAL ADAPTER, 2.4MM COAXIAL, JACK, 2.4MM COAXIAL, JACK, STRAIGHT PANEL ADAPTER, 50 OHM
Description
General part information
RFAA4240 Series
Adapter Coaxial Connector 2.4mm (APC-2.4, OS-50) Jack, Female Socket To 2.4mm (APC-2.4, OS-50) Jack, Female Socket 50 Ohms
Technical Specifications
Parameters and characteristics for this part
| Specification | RFAA4240J240J |
|---|---|
| Adapter Series Size | 2.4 mm |
| Adapter Type | Jack to Jack |
| Body Material | Stainless Steel |
| Center Contact Material | Beryllium Copper |
| Center Gender | Female |
| Conversion Type | Same Series |
| Convert From (Adapter End) Jack Size | 2.4 mm |
| Convert From (Adapter End) Type | Female Socket, APC-2.4, OS-50 |
| Convert To (Adapter End) | Female Socket, Jack |
| Convert To (Adapter End) Gender | Female Socket |
| Convert To (Adapter End) Model | APC-2.4, OS-50 |
| Convert To (Adapter End) Series | OS-50, APC-2.4 |
| Convert To (Adapter End) Size | 2.4 mm |
| Convert To (Adapter End) Type | Jack, Female Socket, 2.4mm (APC-2.4, OS-50) Jack |
| Dielectric Material | Polytetrafluoroethylene (PTFE), Polyetherimide (PEI) |
| Fastening Type | Threaded |
| Frequency - Max | 50 GHz |
| Impedance | 50 Ohm |
| Mating Cycles | 500 cycles |
| Mounting Feature | Flange |
| Mounting Type | Panel Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Style | Straight |
