Specification	KTG2AMB2BBBRN1

Actuator Marking	No Marking
Actuator Type	Convex (Reverse V), Illuminated
Circuit	SPST
Color	Red
Color - Actuator/Cap	Black
Current Rating	21 A, 20 A
Electrical Life (Cycles)	6000 Cycles
Illumination Type	LED
Illumination Voltage (Nominal)	14 VAC/DC
Ingress Protection Description	Water Resistant, Dust Protected
Ingress Protection IP Rating	IP56
Mechanical Life (Cycles)	100000 Cycles
Mounting Type	Panel Mount, Snap-In
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-20 °C
Panel Cutout Length	36.8 mm
Panel Cutout Shape	Rectangular
Panel Cutout Width	15.2 mm
Quick Connect Size (0.250")	0.25 in
Switch Function	On-Off
Termination Style	Quick Connect
Voltage Rating - AC	125 V
Voltage Rating - DC	14 V

KT Series

Part	Ingress Protection IP Rating	Ingress Protection Description	Color - Actuator/Cap	Color	Illumination Type	Switch Function	Panel Cutout Shape	Panel Cutout Length	Panel Cutout Width	Quick Connect Size (0.250")	Termination Style	Voltage Rating - AC	Current Rating	Voltage Rating - DC	Illumination Voltage (Nominal)	Actuator Type	Circuit	Mounting Type	Operating Temperature (Max)	Operating Temperature (Min)	Actuator Marking	Electrical Life (Cycles)	Mechanical Life (Cycles)
ZF Electronics KTG2AMB2BBBRN1	IP56	Dust Protected Water Resistant	Black	Red	LED	On-Off	Rectangular	36.8 mm	15.2 mm	0.25 in	Quick Connect	125 V	20 A 21 A	14 V	14 VAC/DC	Convex (Reverse V) Illuminated	SPST	Panel Mount Snap-In	85 °C	-20 °C	No Marking	6000 Cycles	100000 Cycles
