ASE18X18X8NK
ActiveHoffman Enclosures, Inc.
JUNCTION BOX STEEL 18"L X 18"W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ASE18X18X8NK
ActiveHoffman Enclosures, Inc.
JUNCTION BOX STEEL 18"L X 18"W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | ASE18X18X8NK |
|---|---|
| Area (L x W) | 2090 cm² |
| Area (L x W) | 324 in² |
| Color | Gray |
| Container Type | Junction Box |
| Design | Cover Included |
| Material | Metal, Steel |
| Ratings | NEMA 1, 50E, UL-50, IP30 |
| Size / Dimension [x] | 457 mm |
| Size / Dimension [x] | 17.992 in |
| Size / Dimension [y] | 457 mm |
| Size / Dimension [y] | 17.992 in |
| Weight | 22 lbs |
| Weight | 10 kg |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 97.12 | |
Description
General part information
ASE18X18 Series
Junction Box Metal, Steel Gray Cover Included 17.992" L x 17.992" W (457.00mm x 457.00mm) X 7.992" (203.00mm)
