CMRA6055

Active

Sensata-Crydom

SSR RELAY SPST-NO 55A 48-660V

Search across all available documentation for this part.

Active

Sensata-Crydom

SSR RELAY SPST-NO 55A 48-660V

Technical Specifications

Parameters and characteristics for this part

Specification	CMRA6055

Approval Agency	cURus, CSA, CE
Load Current	55 A
Mounting Type	DIN Rail
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-40 °C
Output Type	AC, Zero Cross
Package / Case	SSR with Integrated Heat Sink
Termination Style	Screw Terminal
Voltage - Input [Max]	140 VAC
Voltage - Input [Min]	90 VAC
Voltage - Load [Max]	660 V
Voltage - Load [Min]	48 V

Part	Voltage - Input [Min]	Voltage - Input [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Load [Min]	Voltage - Load [Max]	Output Type	Mounting Type	Load Current	Package / Case	Termination Style	Approval Agency
Sensata-Crydom CMRA6055	90 VAC	140 VAC	-40 °C	80 C	48 V	660 V	AC Zero Cross	DIN Rail	55 A	SSR with Integrated Heat Sink	Screw Terminal	CE CSA cURus
Sensata-Crydom CMRA6045	90 VAC	140 VAC	-40 °C	80 C	48 V	660 V	AC Zero Cross	DIN Rail	45 A	SSR with Integrated Heat Sink	Screw Terminal	CE CSA cURus

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Solid State SPST-NO (1 Form A) SSR with Integrated Heat Sink
