1-929103-1

Active

TE Connectivity AMP Connectors

CONN PLUG HSG 2POS 3.50MM

Search across all available documentation for this part.

Active

TE Connectivity AMP Connectors

CONN PLUG HSG 2POS 3.50MM

Technical Specifications

Parameters and characteristics for this part

Specification	1-929103-1

Color	Black
Connector Type	Plug
Contact Termination	Crimp
Contact Type	Tab
Insulation Material	Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Number of Positions	2
Number of Rows	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Pitch [x]	3.5 mm
Pitch [x]	0.138 in

CONN PLUG HSG 2POS 3.50MM

Part	Contact Termination	Note	Contact Type	Color	Number of Rows	Connector Type	Number of Positions	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Insulation Material	Pitch [x]	Pitch [x]
TE Connectivity AMP Connectors 1-929103-1	Crimp	Contacts Not Included	Tab	Black	1	Plug	2	Free Hanging (In-Line)	85 °C	-40 °C	Polybutylene Terephthalate (PBT), Glass Filled	3.5 mm	0.138 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2 Rectangular Connectors - Housings Plug Black 0.138" (3.50mm)
