2N2222A

Active

STMicroelectronics

BJT TO92 40V NPN 0.625W 150C

Search across all available documentation for this part.

Active

STMicroelectronics

BJT TO92 40V NPN 0.625W 150C

Technical Specifications

Parameters and characteristics for this part

Specification	2N2222A

Current - Collector (Ic) (Max) [Max]	600 mA
Current - Collector Cutoff (Max) [Max]	0.01 µA
DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	100
Frequency - Transition	300 MHz
Mounting Type	Through Hole
Operating Temperature	175 °C
Package / Case	TO-18-3 Metal Can, TO-206AA
Power - Max [Max]	500 mW
Supplier Device Package	TO-18
Transistor Type	NPN
Vce Saturation (Max) @ Ib, Ic	1 V
Voltage - Collector Emitter Breakdown (Max) [Max]	40 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

BJT TO92 40V NPN 0.625W 150C

Part	Mounting Type	Vce Saturation (Max) @ Ib, Ic	Current - Collector Cutoff (Max) [Max]	Package / Case	Frequency - Transition	Voltage - Collector Emitter Breakdown (Max) [Max]	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Operating Temperature	Transistor Type	Power - Max [Max]	Supplier Device Package	Current - Collector (Ic) (Max) [Max]
STMicroelectronics 2N2222A	Through Hole	1 V	0.01 µA	TO-18-3 Metal Can, TO-206AA	300 MHz	40 V	100	175 °C	NPN	500 mW	TO-18	600 mA

General part information

Bipolar (BJT) Transistor NPN 40 V 600 mA 300MHz 500 mW Through Hole TO-18
