0800488:L3

Active

Phoenix Contact

WIRE MARKER SLIP-ON YELLOW

Search across all available documentation for this part.

Active

Phoenix Contact

WIRE MARKER SLIP-ON YELLOW

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 0.17

General part information

Wire Marker, Slip-On Yellow Ethylene Vinyl Acetate Copolymer (EVA), Halogen Free

Technical documentation and resources

Parameters and characteristics commom to parts in this series

Specification	0800488:L3	0800488 Series

	-	-
Cable Diameter [Max] [diameter]	3.8 mm	3.8 mm
Cable Diameter [Max] [diameter]	0.15 in	0.15 in
Cable Diameter [Min] [diameter]	0.075 in	0.075 in
Cable Diameter [Min] [diameter]	1.9 mm	1.9 mm
Color	Yellow	Yellow
Legend	L3	ERDE, PEN, L2, L3, SERD, WSTR, PE
Material	Ethylene Vinyl Acetate Copolymer (EVA), Halogen Free	Ethylene Vinyl Acetate Copolymer (EVA), Ethylene Vinyl Acetate Copolymer (EVA), Halogen Free
Operating Temperature [Max]	70 °C	70 °C
Operating Temperature [Min]	-45 °C	-45 °C
Size	-	0.13 "
Size	-	3.2 mm
Type	Wire Marker, Slip-On	Wire Marker, Slip-On

WIRE MARKER SLIP-ON YELLOW

Part	Type	Legend	Material	Color	Operating Temperature [Min]	Operating Temperature [Max]	Cable Diameter [Max] [diameter]	Cable Diameter [Max] [diameter]	Cable Diameter [Min] [diameter]	Cable Diameter [Min] [diameter]	Size [x]	Size [x]
Phoenix Contact 0800488:ERDE	Wire Marker, Slip-On	ERDE	Ethylene Vinyl Acetate Copolymer (EVA)	Yellow	-45 °C	70 °C	3.8 mm	0.15 in	0.075 in	1.9 mm
Phoenix Contact 0800488:PEN	Wire Marker, Slip-On	PEN	Ethylene Vinyl Acetate Copolymer (EVA), Halogen Free	Yellow	-45 °C	70 °C	3.8 mm	0.15 in	0.075 in	1.9 mm
Phoenix Contact 0800488:/
Phoenix Contact 0800488:L2	Wire Marker, Slip-On	L2	Ethylene Vinyl Acetate Copolymer (EVA), Halogen Free	Yellow	-45 °C	70 °C	3.8 mm	0.15 in	0.075 in	1.9 mm	0.13 "	3.2 mm
Phoenix Contact 0800488:L3	Wire Marker, Slip-On	L3	Ethylene Vinyl Acetate Copolymer (EVA), Halogen Free	Yellow	-45 °C	70 °C	3.8 mm	0.15 in	0.075 in	1.9 mm
Phoenix Contact 0800488:SERD	Wire Marker, Slip-On	SERD	Ethylene Vinyl Acetate Copolymer (EVA), Halogen Free	Yellow	-45 °C	70 °C	3.8 mm	0.15 in	0.075 in	1.9 mm
Phoenix Contact 0800488:.
Phoenix Contact 0800488:WSTR	Wire Marker, Slip-On	WSTR		Yellow			3.8 mm	0.15 in	0.075 in	1.9 mm	0.13 "	3.2 mm
Phoenix Contact 0800488:PE	Wire Marker, Slip-On	PE	Ethylene Vinyl Acetate Copolymer (EVA), Halogen Free	Yellow	-45 °C	70 °C	3.8 mm	0.15 in	0.075 in	1.9 mm
Phoenix Contact 0800488:+	Wire Marker, Slip-On		Ethylene Vinyl Acetate Copolymer (EVA)	Yellow	-45 °C	70 °C	3.8 mm	0.15 in	0.075 in	1.9 mm
