MT4B3DL-RYG

Active

Menics

COMPLETE UNIT GR/R/Y STEADY 3STK

Search across all available documentation for this part.

Active

Menics

COMPLETE UNIT GR/R/Y STEADY 3STK

Technical Specifications

Parameters and characteristics for this part

Specification	MT4B3DL-RYG

Function - Lighting	Steady
Ingress Protection	IP54 - Dust Protected, Water Resistant
Lamp Type	Incandescent
Light Color	Red, Green, Yellow
Number of Stacks	3
Operating Temperature [Max]	40 °C
Operating Temperature [Min]	-15 °C
Termination Style	Wire Leads
Type	Complete Unit
Voltage - Supply	12 VAC

Part	Operating Temperature [Min]	Operating Temperature [Max]	Light Color	Termination Style	Function - Lighting	Voltage - Supply	Lamp Type	Type	Number of Stacks	Ingress Protection
Menics MT4B3DL-RYG	-15 °C	40 °C	Green Red Yellow	Wire Leads	Steady	12 VAC	Incandescent	Complete Unit	3	IP54 - Dust Protected Water Resistant

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 44.51

General part information

Stack Light Complete Unit Green, Red, Yellow Incandescent Wire Leads
