APG-5A
ActiveOptiFuse
FUSE GLASS 5A 32VDC
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
APG-5A
ActiveOptiFuse
FUSE GLASS 5A 32VDC
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | APG-5A |
|---|---|
| Color | Yellow |
| Current Rating (Amps) | 5 A |
| Mounting Type | Requires Holder |
| Package / Case | Cartridge, Non-Standard |
| Response Time | Fast Blow |
| Size / Dimension [x] | 23 mm |
| Size / Dimension [x] | 0.906 in |
| Size / Dimension [y] | 0.236 in |
| Size / Dimension [y] | 6 mm |
| Size / Dimension [z] | 4 mm |
| Size / Dimension [z] | 0.157 " |
| Voltage Rating - AC | 32 V |
| Voltage Rating - DC | 32 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 1.07 | |
| 10 | $ 1.03 | |||
| 25 | $ 1.01 | |||
| 50 | $ 0.85 | |||
| 100 | $ 0.70 | |||
| 250 | $ 0.63 | |||
| 500 | $ 0.53 | |||
| 1000 | $ 0.46 | |||
Description
General part information
APG-5 Series
5 A 32 V AC 32 V DC Fuse Cartridge, Glass Requires Holder Cartridge, Non-Standard
Documents
Technical documentation and resources
