JN6FR07SM1
ActiveJAE Electronics
CIRCULAR CONNECTOR, 7 CONTACT(S), POLYBUTYLENE TEREPHTHALATE, FEMALE, CRIMP TERMINAL, PLUG
Deep-Dive with AI
Search across all available documentation for this part.
JN6FR07SM1
ActiveJAE Electronics
CIRCULAR CONNECTOR, 7 CONTACT(S), POLYBUTYLENE TEREPHTHALATE, FEMALE, CRIMP TERMINAL, PLUG
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | JN6FR07SM1 |
|---|---|
| Color | Black |
| Connector Type | Plug |
| Contact Termination | Crimp and Clamp |
| Contact Type | Female Socket |
| Features | Waterproof (Mated, IP67) |
| Mounting Type | Free Hanging (In-Line), Right Angle |
| Note | Contacts Not Included |
| Number of Positions | 7 |
| Number of Rows | 2 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 9.62 | |
| 10 | $ 8.53 | |||
| 25 | $ 8.20 | |||
| 50 | $ 7.87 | |||
| 100 | $ 7.70 | |||
Description
General part information
JN6FR07S Series
7 Rectangular Connectors - Housings Plug Black
