EVAL6491HB
ActiveDEMONSTRATION BOARD FOR L6491 GATE DRIVER WITH SMART SHUT DOWN FEATURE
Deep-Dive with AI
Search across all available documentation for this part.
EVAL6491HB
ActiveDEMONSTRATION BOARD FOR L6491 GATE DRIVER WITH SMART SHUT DOWN FEATURE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | EVAL6491HB |
|---|---|
| Contents | Board(s) |
| Embedded | False |
| Function | Half H-Bridge Driver (External FET) |
| Supplied Contents | Board(s) |
| Type | Power Management |
| Utilized IC / Part | L6491 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 95.29 | |
Description
General part information
EVAL6491HB Series
The L6491 is a high voltage device manufactured with the BCD6 "OFF-LINE" technology. It is a single-chip half-bridge gate driver for N-channel power MOSFETs or IGBTs, with a 4 A sink and source current capability.
The high-side (floating) section is designed to stand a voltage rail up to 600 V. The logic inputs are CMOS/TTL compatible down to 3.3 V for easy interfacing a microcontroller or DSP.
An integrated comparator is available for fast overcurrent protection, and is also suited for other functions such overtemperature, etc.
