EVB-USB5816
ActiveMicrochip Technology
EVB-USB5816 EVALUATION BOARD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
EVB-USB5816
ActiveMicrochip Technology
EVB-USB5816 EVALUATION BOARD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | EVB-USB5816 | USB5816 Series |
|---|---|---|
| - | - | |
| Function | USB 2.0 Hub | Hub Controller, USB 2.0 Hub |
| Interface | - | I2C, SPI |
| Operating Temperature | - | 70 - 85 °C |
| Operating Temperature | - | -40 - 0 °C |
| Package / Case | - | 100-VFQFN Exposed Pad |
| Protocol | - | USB |
| Standards | - | USB 3.1 |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 100-VQFN (12x12) |
| Type | Interface | Interface |
| Utilized IC / Part | USB5816 | USB5816 |
| Voltage - Supply | - | 1.08 - 3 V |
| Voltage - Supply | - | 1.32 - 3.6 V |
| Voltage - Supply | - | 1.2 - 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 363.85 | |
USB5816 Series
6-PORT USB SS / HI-SPEED HUB CONTROLLER
| Part | Voltage - Supply [Min] | Voltage - Supply [Max] | Supplier Device Package | Operating Temperature [Max] | Operating Temperature [Min] | Function | Protocol | Package / Case | Standards | Interface | Voltage - Supply | Supplied Contents | Utilized IC / Part | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Microchip Technology USB5816CT/KD | 1.08 V, 3 V | 1.32 V, 3.6 V | 100-VQFN (12x12) | 70 °C | 0 °C | Hub Controller | USB | 100-VFQFN Exposed Pad | USB 3.1 | I2C, SPI | ||||
Microchip Technology USB5816-I/KD | 100-VQFN (12x12) | 85 °C | -40 °C | Hub Controller | USB | 100-VFQFN Exposed Pad | USB 3.1 | I2C, SPI | 1.2 V, 3.3 V | |||||
Microchip Technology USB5816/KD | 100-VQFN (12x12) | 70 °C | 0 °C | Hub Controller | USB | 100-VFQFN Exposed Pad | USB 3.1 | I2C, SPI | 1.2 V, 3.3 V | |||||
Microchip Technology USB5816T/KD | 100-VQFN (12x12) | 70 °C | 0 °C | Hub Controller | USB | 100-VFQFN Exposed Pad | USB 3.1 | I2C, SPI | 1.2 V, 3.3 V | |||||
Microchip Technology USB5816C/KD | 1.08 V, 3 V | 1.32 V, 3.6 V | 100-VQFN (12x12) | 70 °C | 0 °C | Hub Controller | USB | 100-VFQFN Exposed Pad | USB 3.1 | I2C, SPI | ||||
Microchip Technology EVB-USB5816 | USB 2.0 Hub | Board(s) | USB5816 | Interface | ||||||||||
Microchip Technology USB5816C-I/KD | 1.08 V, 3 V | 1.32 V, 3.6 V | 100-VQFN (12x12) | 85 °C | -40 °C | Hub Controller | USB | 100-VFQFN Exposed Pad | USB 3.1 | I2C, SPI | ||||
Microchip Technology USB5816C-I/KD |
Description
General part information
USB5816 Series
USB5816 USB 2.0 Hub Interface Evaluation Board
