MIXA60WH1200TEH

Obsolete

IXYS

IGBT MODULE 1200V 85A 290W E3

Search across all available documentation for this part.

Obsolete

IXYS

IGBT MODULE 1200V 85A 290W E3

Technical Specifications

Parameters and characteristics for this part

Specification	MIXA60WH1200TEH

Configuration	Brake, Three Phase Inverter
Current - Collector (Ic) (Max) [Max]	85 A
Current - Collector Cutoff (Max) [Max]	500 çA
Input	Three Phase Bridge Rectifier
Mounting Type	Chassis Mount
NTC Thermistor	True
Package / Case	E3
Power - Max [Max]	290 W
Supplier Device Package	E3
Vce(on) (Max) @ Vge, Ic	2.1 V
Voltage - Collector Emitter Breakdown (Max) [Max]	1200 V

Part	Voltage - Collector Emitter Breakdown (Max) [Max]	Current - Collector Cutoff (Max) [Max]	Input	Vce(on) (Max) @ Vge, Ic	IGBT Type	Configuration	Package / Case	Power - Max [Max]	Mounting Type	Current - Collector (Ic) (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Supplier Device Package
IXYS MIXA60HU1200VA	1200 V	500 çA	Standard	2.1 V	PT	2 Independent	V1A-PAK	290 W	Chassis Mount	85 A	150 °C	-40 °C	V1A-PAK
IXYS MIXA60WH1200TEH	1200 V	500 çA	Three Phase Bridge Rectifier	2.1 V		Brake Three Phase Inverter	E3	290 W	Chassis Mount	85 A			E3
IXYS MIXA60W1200TED	1200 V	500 çA	Standard	2.1 V	PT	Brake Three Phase Inverter	E2	290 W	Chassis Mount	85 A	125 ¯C	-40 °C	E2

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

IGBT Module Three Phase Inverter with Brake 1200 V 85 A 290 W Chassis Mount E3

Technical documentation and resources

No documents available
