TUHS5F12

Active

Cosel USA, Inc.

AC/DC CONVERTER 12V 5W

Search across all available documentation for this part.

Active

Cosel USA, Inc.

AC/DC CONVERTER 12V 5W

Technical Specifications

Parameters and characteristics for this part

Part	Mounting Type	Load Regulation	Efficiency	Voltage - Output 1	Features	Line Regulation	Current - Output (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input [Min]	Voltage - Input [Max]	Type	Approval Agency	Power (Watts)	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Package / Case	Number of Outputs	Applications
Cosel USA, Inc. TUHS5F05	Through Hole	40 mV	79 %	5 V	Universal Input	20 mV	1 A	85 °C	-40 °C	85 VAC 120 VDC	264 VAC 370 VDC	Enclosed	CE cURus	5 W	0.69 "	12.7 mm	17.5 mm	28.7 mm	0.5 in	1.13 in	6-DIP Module	1	ITE (Commercial)
Cosel USA, Inc. TUHS5F24	Through Hole	150 mV	83 %	24 V	Universal Input	96 mV	220 mA	85 °C	-40 °C	85 VAC 120 VDC	264 VAC 370 VDC	Enclosed	CE cURus	5 W	0.69 "	12.7 mm	17.5 mm	28.7 mm	0.5 in	1.13 in	6-DIP Module	1	ITE (Commercial)
Cosel USA, Inc. TUHS5F12	Through Hole	100 mV		12 V	Universal Input	48 mV	450 mA	85 °C	-40 °C	85 VAC 120 VDC	264 VAC 370 VDC	Enclosed	CE cURus	5 W	0.69 "	12.7 mm	17.5 mm	28.7 mm	0.5 in	1.13 in	6-DIP Module	1	ITE (Commercial)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Enclosed AC DC Converters 1 Output 12V 450mA 85 ~ 264 VAC, 120 ~ 370 VDC Input
