XPEBPA-L1-R250-00B01

Active

Cree LED

LED XLAMP XPE2 AMBER SMD

Search across all available documentation for this part.

Active

Cree LED

LED XLAMP XPE2 AMBER SMD

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	XPEBPA-L1-R250-00B01	XPEBPA Series

Color	Amber	Amber
Current - Max [Max]	1 A	1 A
Current - Test	350 mA	350 mA
Height - Seated (Max) [Max] [z]	2.39 mm	2.39 mm
Height - Seated (Max) [Max] [z]	0.094 "	0.094 "
Lumens/Watt @ Current - Test	91 lm/W	85 - 97 lm/W
Luminous Flux @ Current/Temperature	97 lm	91 - 104 lm
Luminous Flux @ Current/Temperature	-	87 - 100 lm
Luminous Flux @ Current/Temperature	-	94 - 107 lm
Mounting Type	Surface Mount	Surface Mount
Package / Case	3535 Metric	3535 Metric
Package / Case	1414	1414
Size / Dimension [x]	3.45 mm	3.45 mm
Size / Dimension [x]	0.136 in	0.136 in
Size / Dimension [y]	0.136 in	0.136 in
Size / Dimension [y]	3.45 mm	3.45 mm
Supplier Device Package	SMD	SMD
Thermal Resistance of Package [diameter]	9 °C/W	9 °C/W
Viewing Angle	110 °	110 °
Voltage - Forward (Vf) (Typ)	2.94 V	2.94 V

LED XLAMP XPE2 AMBER SMD

Part	Viewing Angle	Voltage - Forward (Vf) (Typ)	Package / Case	Package / Case	Mounting Type	Color	Thermal Resistance of Package [diameter]	Lumens/Watt @ Current - Test	Luminous Flux @ Current/Temperature [Min]	Luminous Flux @ Current/Temperature	Luminous Flux @ Current/Temperature [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Supplier Device Package	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Current - Test	Current - Max [Max]
Cree LED XPEBPA-L1-R250-00A01	110 °	2.94 V	3535 Metric	1414	Surface Mount	Amber	9 °C/W	85 lm/W	87 lm	91 lm	94 lm	2.39 mm	0.094 "	SMD	3.45 mm	0.136 in	0.136 in	3.45 mm	350 mA	1 A
Cree LED XPEBPA-L1-R250-00B01	110 °	2.94 V	3535 Metric	1414	Surface Mount	Amber	9 °C/W	91 lm/W		97 lm		2.39 mm	0.094 "	SMD	3.45 mm	0.136 in	0.136 in	3.45 mm	350 mA	1 A
Cree LED XPEBPA-L1-R250-00C01	110 °	2.94 V	3535 Metric	1414	Surface Mount	Amber	9 °C/W	97 lm/W	100 lm	104 lm	107 lm	2.39 mm	0.094 "	SMD	3.45 mm	0.136 in	0.136 in	3.45 mm	350 mA	1 A
Cree LED XPEBPA-L1-0000-00B01	110 °	2.94 V	3535 Metric	1414	Surface Mount	Amber	9 °C/W	91 lm/W		97 lm		2.39 mm	0.094 "	SMD	3.45 mm	0.136 in	0.136 in	3.45 mm	350 mA	1 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	250	$ 1.98

General part information

LED Lighting Color XLamp® XP-E2 Amber 1414 (3535 Metric)
