T21MU4KCI

Active

Temprel

4" PROBE LENGTH X 1/8" PROBE DIA

Search across all available documentation for this part.

Active

Temprel

4" PROBE LENGTH X 1/8" PROBE DIA

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	T21MU4KCI	T21MU4 Series

Plug Color	Yellow	Yellow
Plug Type	Sub-Mini (Thermocouple Plug)	Sub-Mini (Thermocouple Plug)
Probe Length	4 in	4 in
Probe Length	101.6 mm	101.6 mm
Probe Material	Inconel	Inconel
Probe Temperature Range [Max]	1250 °C	1250 °C
Probe Temperature Range [Min]	-200 °C	-200 °C
Tip Type	Immersion / Penetration, Rounded	Immersion / Penetration, Rounded
Type	K-Type Thermocouple	K-Type Thermocouple
Usage	Semi Solids, Liquids	Semi Solids, Liquids

4" PROBE LENGTH X 1/8" PROBE DIA

Part	Probe Material	Plug Type	Tip Type	Probe Length	Probe Length	Probe Temperature Range [Max]	Probe Temperature Range [Min]	Usage	Type	Plug Color
Temprel T21MU4KCI	Inconel	Sub-Mini (Thermocouple Plug)	Immersion / Penetration, Rounded	4 in	101.6 mm	1250 °C	-200 °C	Liquids, Semi Solids	K-Type Thermocouple	Yellow
Temprel T21MU4KAI	Inconel	Sub-Mini (Thermocouple Plug)	Immersion / Penetration, Rounded	4 in	101.6 mm	1250 °C	-200 °C	Liquids, Semi Solids	K-Type Thermocouple	Yellow

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 36.16

General part information

K-Type Thermocouple Immersion / Penetration, Rounded -328 ~ 2282°F (-200 ~ 1250°C)

Technical documentation and resources

No documents available
