MN13TXW13

Active

NKK Switches

SWITCH ROCKER MINI PC MOUNT

Search across all available documentation for this part.

Active

NKK Switches

SWITCH ROCKER MINI PC MOUNT

Technical Specifications

Parameters and characteristics for this part

Part	Voltage Rating - DC	Current Rating (Amps)	Electrical Life	Switch Function	Actuator Marking	Circuit	Actuator Type	Operating Temperature [Min]	Operating Temperature [Max]	Termination Style	Mounting Type	Approval Agency	Voltage Rating - AC	Color - Actuator/Cap
NKK Switches MN13TXG13
NKK Switches MN13TXW41-DH	30 V	3 A 6 A	25000 Steps	On-Off-On	No Marking	SPDT	Concave (Standard V)	-30 ░C	85 °C	PC Pin	Right Angle Through Hole Vertical	UL	125 V
NKK Switches MN13TXW13-FC	30 V	3 A 6 A	25000 Steps	On-Off-On	No Marking	SPDT	Concave (Standard V)	-30 ░C	85 °C	PC Pin	Through Hole	UL	125 V	Red
NKK Switches MN13TXG13-FA
NKK Switches MN13TXW13-DA	30 V	3 A 6 A	25000 Steps	On-Off-On	No Marking	SPDT	Concave (Standard V)	-30 ░C	85 °C	PC Pin	Through Hole	UL	125 V	Black
NKK Switches MN13TXW13-DF	30 V	3 A 6 A	25000 Steps	On-Off-On	No Marking	SPDT	Concave (Standard V)	-30 ░C	85 °C	PC Pin	Through Hole	UL	125 V	Green
NKK Switches MN13TXW13	30 V	3 A 6 A	25000 Steps	On-Off-On	No Marking	SPDT	Actuator Arm Cap Required	-30 ░C	85 °C	PC Pin	Through Hole	UL	125 V
NKK Switches MN13TXG13-EA
NKK Switches MN13TXW41	30 V	3 A 6 A	25000 Steps	On-Off-On	Varies by Cap	SPDT	Actuator Arm Cap Required	-30 ░C	85 °C	PC Pin	Right Angle Through Hole Vertical	UL	125 V
NKK Switches MN13TXG13-DA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Rocker Switch SPDT 6A (AC), 3A (DC) 125 V Through Hole

Technical documentation and resources

No documents available
