EA-LCD-011

Obsolete

Embedded Artists

EXPANSION KIT DISPLAY 4.3 INCH

Search across all available documentation for this part.

Obsolete

Embedded Artists

EXPANSION KIT DISPLAY 4.3 INCH

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	EA-LCD-011	EA-LCD Series

Backlight	LED - White	LED - White
Diagonal Screen Size	109.22 mm	109.22 - 177.8 mm
Diagonal Screen Size	4.3 in	4.3 - 7 in
Display Mode	Transmissive	Transmissive
Display Type	TFT - Color	TFT - Color
Dot Pixels	-	WVGA
Dot Pixels [x]	480	480 - 800
Dot Pixels [y]	272	272 - 480
Dot Size	-	0.06 mm
Dot Size [y]	0.2 mm	0.19 - 0.2 mm
Dot Size [z]	0.2 mm	0.2 mm
Function	-	Embedded Graphics
Graphics Color	Green, Red, Blue	Green, Red, Blue
Interface	Parallel	Parallel, Parallel/Serial, I2C, SPI
Interface	24 Bit	24 Bit
Supplied Contents	-	Cable(s), Board(s)
Touchscreen	-	Resistive
Type	-	Display
Viewing Area	-	91.44 mm
Viewing Area [x]	95.04 mm	95.04 - 152.4 mm
Viewing Area [y]	53.86 mm	53.86 mm

EXPANSION KIT DISPLAY 4.3 INCH

Part	Display Mode	Diagonal Screen Size	Diagonal Screen Size	Graphics Color	Backlight	Dot Pixels [y]	Dot Pixels [x]	Display Type	Interface	Interface	Dot Size [y]	Dot Size [z]	Viewing Area [y]	Viewing Area [x]	Touchscreen	Viewing Area [z]	Dot Size [x]	Dot Pixels	Function	Type	Supplied Contents
Embedded Artists EA-LCD-011	Transmissive	109.22 mm	4.3 in	Blue, Green, Red	LED - White	272	480	TFT - Color	Parallel	24 Bit	0.2 mm	0.2 mm	53.86 mm	95.04 mm
Embedded Artists EA-LCD-006	Transmissive	177.8 mm	7 in	Blue, Green, Red	LED - White	480	800	TFT - Color	Parallel/Serial		0.19 mm			152.4 mm	Resistive	91.44 mm	0.06 mm	WVGA
Embedded Artists EA-LCD-010																			Embedded Graphics	Display	Board(s), Cable(s)
Embedded Artists EA-LCD-004	Transmissive	109.22 mm	4.3 in	Blue, Green, Red	LED - White	272	480	TFT - Color	I2C, SPI		0.2 mm	0.2 mm			Resistive

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 38.64

General part information

Graphic LCD Display Module Transmissive Red, Green, Blue (RGB) TFT - Color Parallel, 24-Bit (RGB) 4.3" (109.22mm) 480 x 272
