EST158M016AH5AA

Active

KEMET

CAP ALUM 1500UF 20% 16V RADIAL

Search across all available documentation for this part.

Active

KEMET

CAP ALUM 1500UF 20% 16V RADIAL

Technical Specifications

Parameters and characteristics for this part

Specification	EST158M016AH5AA

Applications	General Purpose
Capacitance	1.5 mF
ESR (Equivalent Series Resistance)	52 mOhm
Height - Seated (Max) [Max] [z]	1.063 in
Height - Seated (Max) [Max] [z]	27 mm
Lead Spacing	5 mm
Lead Spacing	0.197 in
Lifetime @ Temp.	6000 Hrs
Mounting Type	Through Hole
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can
Polarization	Polar
Ripple Current @ High Frequency	1.65 A
Ripple Current @ Low Frequency	990 mA
Size / Dimension [diameter]	10 mm
Size / Dimension [diameter]	0.394 in
Tolerance	20 %
Voltage - Rated	16 V

Part	ESR (Equivalent Series Resistance)	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Polarization	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Capacitance	Lead Spacing	Lead Spacing	Size / Dimension [diameter]	Size / Dimension [diameter]	Ripple Current @ High Frequency	Voltage - Rated	Ripple Current @ Low Frequency	Tolerance	Mounting Type	Lifetime @ Temp.	Applications
KEMET EST158M016AH5AA	52 mOhm	-40 °C	105 ░C	Radial Can	Polar	1.063 in	27 mm	1.5 mF	5 mm	0.197 in	10 mm	0.394 in	1.65 A	16 V	990 mA	20 %	Through Hole	6000 Hrs	General Purpose

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

1500 µF 16 V Aluminum Electrolytic Capacitors Radial, Can 52mOhm @ 100kHz 6000 Hrs @ 105°C
