MIC5219-3.3BMM TS

Active

Micrel Inc.

500MA PEAK OUTPUT LDO REGULATOR

Search across all available documentation for this part.

Active

Micrel Inc.

500MA PEAK OUTPUT LDO REGULATOR

Technical Specifications

Parameters and characteristics for this part

Specification	MIC5219-3.3BMM TS

Control Features	Enable, Current Limit
Current - Output	500 mA
Current - Quiescent (Iq)	170 µA
Current - Supply (Max) [Max]	25 mA
Mounting Type	Surface Mount
Number of Regulators	1
Operating Temperature [Max]	125 ¯C
Operating Temperature [Min]	-40 °C
Output Configuration	Positive
Output Type	1.81 mOhm
Package / Case	8-MSOP, 8-TSSOP
Package / Case	3 mm
Package / Case [custom]	0.118 in
Protection Features	Over Temperature, Reverse Polarity, Over Current
PSRR	75 dB
Supplier Device Package	8-MSOP
Voltage - Input (Max) [Max]	12 V
Voltage - Output (Min/Fixed)	3.3 V
Voltage Dropout (Max) [Max]	0.6 V

500MA PEAK OUTPUT LDO REGULATOR

Part	Current - Supply (Max) [Max]	Protection Features	Operating Temperature [Min]	Operating Temperature [Max]	Current - Quiescent (Iq)	Control Features	Output Configuration	Package / Case	Package / Case [custom]	Package / Case	Supplier Device Package	Output Type	Mounting Type	Voltage - Output (Min/Fixed)	Number of Regulators	PSRR	Current - Output	Voltage - Input (Max) [Max]	Voltage Dropout (Max) [Max]
Micrel Inc. MIC5219-3.3BMM TS	25 mA	Over Current, Over Temperature, Reverse Polarity	-40 °C	125 ¯C	170 µA	Current Limit, Enable	Positive	8-MSOP, 8-TSSOP	0.118 in	3 mm	8-MSOP	1.81 mOhm	Surface Mount	3.3 V	1	75 dB	500 mA	12 V	0.6 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	579	$ 0.52

General part information

Linear Voltage Regulator IC Positive Fixed 1 Output 500mA 8-MSOP
