XVO2LUGY86M
ActiveSunLED
LED CBI 3MM BI-LVL GRN/YLW RA
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
XVO2LUGY86M
ActiveSunLED
LED CBI 3MM BI-LVL GRN/YLW RA
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | XVO2LUGY86M |
|---|---|
| Color | Green (x 1), Yellow (x 1) |
| Configuration | 2 High |
| Current | 140 mA, 140 mA |
| Lens Size | 3 mm |
| Lens Size | T-1 |
| Lens Style | Round with Domed Top |
| Lens Type | Diffused, White |
| Millicandela Rating | 39 mcd, 19 mcd |
| Mounting Type | Through Hole, Right Angle |
| Viewing Angle | 60 ° |
| Voltage Rating | 2.1 V, 2.2 V |
| Wavelength - Peak [custom] | 565 nm, 590 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 1.46 | |
| 10 | $ 1.03 | |||
| 250 | $ 0.71 | |||
| 500 | $ 0.66 | |||
| 1000 | $ 0.63 | |||
| 2000 | $ 0.59 | |||
| 5000 | $ 0.56 | |||
| 10000 | $ 0.54 | |||
Description
General part information
XVO2LUGY86 Series
LED Circuit Board Indicator LED Circuit Board Indicator 2 High Green (x 1 ), Yellow (x 1) Diffused, White 2.2V Green, 2.1V Yellow 140mA Green, 140mA Yellow Round with Domed Top 3mm, T-1 Through Hole, Right Angle
