CMRD2455

Active

Sensata-Crydom

SSR RELAY SPST-NO 55A 24-280V

Search across all available documentation for this part.

Active

Sensata-Crydom

SSR RELAY SPST-NO 55A 24-280V

Technical Specifications

Parameters and characteristics for this part

Specification	CMRD2455

Approval Agency	cURus, CSA, CE
Load Current	55 A
Mounting Type	DIN Rail
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-40 °C
Output Type	AC, Zero Cross
Package / Case	SSR with Integrated Heat Sink
Termination Style	Screw Terminal
Voltage - Input [Max]	32 V
Voltage - Input [Min]	3 V
Voltage - Load [Max]	280 V
Voltage - Load [Min]	24 V

Part	Output Type	Approval Agency	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Termination Style	Voltage - Input [Max]	Voltage - Input [Min]	Voltage - Load [Min]	Voltage - Load [Max]	Package / Case	Load Current
Sensata-Crydom CMRD2435	AC Zero Cross	CE CSA cURus	-40 °C	80 C	DIN Rail	Screw Terminal	32 V	3 V	24 V	280 V	SSR with Integrated Heat Sink	35 A
Sensata-Crydom CMRD2455	AC Zero Cross	CE CSA cURus	-40 °C	80 C	DIN Rail	Screw Terminal	32 V	3 V	24 V	280 V	SSR with Integrated Heat Sink	55 A
Sensata-Crydom CMRD2465-10	AC	CE CSA cURus	-40 °C	80 C	DIN Rail	Screw Terminal	32 V	3 V	24 V	280 V	SSR with Integrated Heat Sink	65 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Solid State SPST-NO (1 Form A) SSR with Integrated Heat Sink
