1953224

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 4 POS 3.5MM PITCH THROUGH HOLE HEADER

Search across all available documentation for this part.

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 4 POS 3.5MM PITCH THROUGH HOLE HEADER

Technical Specifications

Parameters and characteristics for this part

Specification	1953224

Color	Black
Contact Mating Finish	Tin
Contact Tail Length	0.055 in
Contact Tail Length	1.4 mm
Current - IEC	8 A
Current - UL	8 A
Features	Locking Ramp
Header Orientation	90°, Right Angle
Housing Material	Liquid Crystal Polymer (LCP)
Insulation Height	15.19 mm
Insulation Height	0.598 "
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Levels	2
Number of Positions	8
Pitch [x]	3.5 mm
Pitch [x]	0.138 in
Positions Per Level	4
Termination Style	Solder
Type	Header, Male Pins, Shrouded (4 Side)
Voltage - IEC	250 V
Voltage - UL	150 V

Pluggable Terminal Blocks 20 Pos 3.5mm pitch Through Hole Header

Part	Voltage - IEC	Current - UL	Termination Style	Number of Positions	Housing Material	Positions Per Level	Contact Tail Length	Contact Tail Length	Contact Mating Finish	Insulation Height	Insulation Height	Material Flammability Rating	Color	Current - IEC	Type	Features	Number of Levels	Pitch [x]	Pitch [x]	Mounting Type	Header Orientation	Voltage - UL
Phoenix Contact 1953224	250 V	8 A	Solder	8	Liquid Crystal Polymer (LCP)	4	0.055 in	1.4 mm	Tin	15.19 mm	0.598 "	UL94 V-0	Black	8 A	Header, Male Pins, Shrouded (4 Side)	Locking Ramp	2	3.5 mm	0.138 in	Through Hole	90°, Right Angle	150 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pluggable Terminal Blocks 20 Pos 3.5mm pitch Through Hole Header
