MSAS-12PFFS-SF8002

Active

Amphenol LTW

M SERIES SENSOR CONNECTOR, M12, A CODE, METAL, 1.5A, 12 PINS, FEMALE CONNECTOR, FEMALE CONTACT, HEXAGONAL, M16*1.5, SCREW THREAD

Search across all available documentation for this part.

Active

Amphenol LTW

M SERIES SENSOR CONNECTOR, M12, A CODE, METAL, 1.5A, 12 PINS, FEMALE CONNECTOR, FEMALE CONTACT, HEXAGONAL, M16*1.5, SCREW THREAD

Technical Specifications

Parameters and characteristics for this part

Specification	MSAS-12PFFS-SF8002

Color	Black
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	1.5 A
Ingress Protection	IP68, IP69K
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Bulkhead - Front Side Nut
Number of Positions	12
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	A
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	M12-12
Shielding	Shielded
Voltage Rating	30 VAC

Part	Operating Temperature [Min]	Operating Temperature [Max]	Primary Material	Color	Shielding	Connector Type	Shell Material	Contact Finish - Mating	Shell Size - Insert	Orientation	Number of Positions	Ingress Protection	Mounting Feature	Insert Material	Voltage Rating	Current Rating (Amps)	Contact Material
Amphenol LTW MSAS-12PFFS-SF8002	-40 °C	105 ░C	Plastic	Black	Shielded	Receptacle Female Sockets	Glass Filled Nylon Polyamide (PA)	Gold	M12-12	A	12	IP68 IP69K	Bulkhead - Front Side Nut	Polyamide (PA) Nylon Glass Filled	30 VAC	1.5 A	Copper Alloy

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

12 Position Circular Connector Receptacle, Female Sockets Solder Cup
