5VB1
ActiveTE Connectivity Raychem Cable Protection
5VB1=F7126 S0
Deep-Dive with AI
Search across all available documentation for this part.
5VB1
ActiveTE Connectivity Raychem Cable Protection
5VB1=F7126 S0
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 5VB1 |
|---|---|
| Applications | General Purpose |
| Approval Agency | VDE, CSA, UR |
| Configuration | Single Stage |
| Current | 5 A |
| Filter Type | Single Phase |
| Frequency - Operating [Max] | 60 Hz |
| Frequency - Operating [Min] | 50 Hz |
| Inductance | 516 µH |
| Mounting Type | Chassis Mount |
| Operating Temperature [Max] | 40 °C |
| Operating Temperature [Min] | -10 °C |
| Termination Style | Quick Connect |
| Voltage - Rated AC | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 15.85 | |
| 10 | $ 13.41 | |||
| 36 | $ 13.01 | |||
| 72 | $ 12.20 | |||
| 108 | $ 10.98 | |||
| 252 | $ 10.57 | |||
| 504 | $ 10.16 | |||
Description
General part information
Corcom B Series
5 A Single Phase Filter, FASTON Input, .250" FASTON Output, 250 VAC, Corcom B, Single Phase Filters
