1-1102100-7
ActiveTE Connectivity AMP Connectors
CONN HOOD TOP ENTRY SZ1 PG11
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
1-1102100-7
ActiveTE Connectivity AMP Connectors
CONN HOOD TOP ENTRY SZ1 PG11
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 1-1102100-7 |
|---|---|
| Connector Type | Hood |
| Housing Color | Gray |
| Housing Finish | Powder Coated |
| Housing Material | Zinc, Die Cast |
| Lock Location | Locking Clip (1) on Base Bottom |
| Size | 1 Gallon |
| Size / Dimension [x] | 1.043 in |
| Size / Dimension [x] | 26.5 mm |
| Size / Dimension [y] | 1.043 " |
| Size / Dimension [y] | 26.5 mm |
| Size / Dimension [z] | 2.047 in |
| Size / Dimension [z] | 52 mm |
| Style | Top Entry |
| Thread Size | PG11 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 640 | $ 13.64 | |
1102100 Series
CONN HOOD TOP ENTRY SZ1 PG11
| Part | Housing Color | Thread Size | Size | Lock Location | Housing Finish | Style | Connector Type | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Housing Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors 1-1102100-7 | Gray | PG11 | 1 Gallon | Locking Clip (1) on Base Bottom | Powder Coated | Top Entry | Hood | 1.043 in | 2.047 in | 26.5 mm | 1.043 " | 52 mm | 26.5 mm | Zinc, Die Cast |
Description
General part information
1102100 Series
Hood Connector Top Entry PG11 1
