T3AFG5

Obsolete

Teledyne LeCroy

5 MHZ, 125 MS/S, 16 KPTS, 1 CH, 20 VPP FUNCTION/ARBITRARY WAVEFORM GENERATOR

Search across all available documentation for this part.

Obsolete

Teledyne LeCroy

5 MHZ, 125 MS/S, 16 KPTS, 1 CH, 20 VPP FUNCTION/ARBITRARY WAVEFORM GENERATOR

Technical Specifications

Parameters and characteristics for this part

Part	Number of Channels	Function	Frequency - Max [Max]	Display Type	Type	Signal Types	Number of Channels [custom]
Teledyne LeCroy T3AFG5	1	Arbitrary Sweep	5 MHz	TFT - Color LCD	Function Generator	Pulse Ramp Sine Square
Teledyne LeCroy T3AFG80		Arbitrary Sweep	80 MHz	TFT - Color LCD	Function Generator	Pulse Ramp Sine Square	2
Teledyne LeCroy T3AFG40		Arbitrary Sweep	40 MHz	TFT - Color LCD	Function Generator	Pulse Ramp Sine Square	2
Teledyne LeCroy T3AFG120		Arbitrary Sweep	120 MHz	TFT - Color LCD	Function Generator	Pulse Ramp Sine Square	2

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

5 MHz Arbitrary, Sweep Function Generator 1 Channel Sine, Square, Ramp, Pulse Display Type TFT - Color LCD
