LCR-U02002DSF-WH

Active

Lumex Opto/Components Inc.

LCD MOD 40DIG 20X2 TRANSFLCT WHT

Search across all available documentation for this part.

Active

Lumex Opto/Components Inc.

LCD MOD 40DIG 20X2 TRANSFLCT WHT

Technical Specifications

Parameters and characteristics for this part

LCD MOD 40DIG 20X2 TRANSFLCT WHT

Part	Display Mode	Display Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Character Format [y]	Character Format [x]	Interface	Operating Temperature [Max]	Operating Temperature [Min]	Background Color	Number of Characters	Dot Size [custom]	Dot Size [custom]	Viewing Area [y]	Viewing Area [x]	Display Format [x]	Display Format [y]	Backlight	Outline L x W x H [x]	Outline L x W x H [z]	Outline L x W x H [y]
Lumex Opto/Components Inc. LCR-U02002DSF-WH	Transflective	STN - Super-Twisted Nematic	4.7 V	5.3 V	8 Dots	5 Dots	Parallel	85 °C	-40 °C	Green	40	0.65 mm	0.6 mm	18.6 mm	83 mm	20	2	LED - White	116 mm	9.8 mm	37 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Character Display Module Transflective 5 x 8 Dots STN - Super-Twisted Nematic LED - White Parallel 116.00mm x 37.00mm x 9.80mm

Technical documentation and resources

No documents available
