BMD-330-EVAL

Active

u-blox

EVAL BOARD FOR BMD-330 NRF52810

Search across all available documentation for this part.

Active

u-blox

EVAL BOARD FOR BMD-330 NRF52810

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	BMD-330-EVAL	BMD-330 Series

Antenna Type	-	Integrated, Trace
Current - Receiving	-	11.2 mA
Current - Transmitting	-	15 mA
Data Rate	-	2 Mbps
For Use With/Related Products	BMD-330, nRF52810	BMD-330, nRF52810
Frequency	2.4 GHz	2.4 GHz
Frequency	-	2.5 GHz
Frequency	-	2.3 GHz
Memory Size	-	24 - 192 kB
Modulation	-	GFSK
Mounting Type	-	Surface Mount
Operating Temperature	-	85 °C
Operating Temperature	-	-40 °C
Package / Case	-	47-SMD Module
Power - Output	-	4 dBm
Protocol	-	Bluetooth v5.0
RF Family/Standard	-	Bluetooth
Serial Interfaces	-	SPI, I2C, I2S, UART
Supplied Contents	Board(s)	Board(s)
Type	Transceiver, Bluetooth® 5.x (BLE)	Transceiver, Bluetooth® 5.x (BLE)
Utilized IC / Part	-	nRF52810
Voltage - Supply	-	3.6 V
Voltage - Supply	-	1.7 V

EVAL BOARD FOR BMD-330 NRF52810

Part	Type	For Use With/Related Products	Frequency	Supplied Contents	Operating Temperature [Max]	Operating Temperature [Min]	Modulation	Memory Size	RF Family/Standard	Package / Case	Power - Output	Utilized IC / Part	Current - Receiving	Frequency [Max]	Frequency [Min]	Mounting Type	Antenna Type	Data Rate	Serial Interfaces	Voltage - Supply [Max]	Voltage - Supply [Min]	Current - Transmitting	Protocol
u-blox BMD-330-EVAL	Bluetooth® 5.x (BLE), Transceiver	BMD-330, nRF52810	2.4 GHz	Board(s)
u-blox BMD-330-A-R					85 °C	-40 °C	GFSK	24 kB, 192 kB	Bluetooth	47-SMD Module	4 dBm	nRF52810	11.2 mA	2.5 GHz	2.3 GHz	Surface Mount	Integrated, Trace	2 Mbps	I2C, I2S, SPI, UART	3.6 V	1.7 V	15 mA	Bluetooth v5.0

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 69.00

General part information

- BMD-330, nRF52810 Transceiver; Bluetooth® 5.x (BLE) 2.4GHz Evaluation Board
