Technical Specifications
Parameters and characteristics for this part
| Specification | PSD-6M-01 |
|---|---|
| Between Board Height | 6 mm |
| Between Board Height | 0.236 in |
| Holding Type | Snap Lock |
| Length - Overall [x] | 0.447 in |
| Length - Overall [x] | 11.35 mm |
| Material | Nylon |
| Mounting Type | Resting Mount |
| Support Hole Diameter [diameter] | 0.122 in |
| Support Hole Diameter [diameter] | 3.1 mm |
| Support Panel Thickness | 0.0625 " |
| Support Panel Thickness | 0.062 " |
| Support Panel Thickness | 1.57 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 0.35 | |
| 10 | $ 0.30 | |||
| 25 | $ 0.26 | |||
| 50 | $ 0.24 | |||
| 100 | $ 0.23 | |||
| 250 | $ 0.21 | |||
| 500 | $ 0.20 | |||
| 1000 | $ 0.16 | |||
| 3000 | $ 0.15 | |||
Description
General part information
PSD-6M Series
Board Support Snap Lock / Resting Mount Nylon 0.236" (6.00mm)
