684-60RED

Active

E-Z-Hook

TEST LEAD GATOR TO GATOR 60"

Search across all available documentation for this part.

Active

E-Z-Hook

TEST LEAD GATOR TO GATOR 60"

Technical Specifications

Parameters and characteristics commom to parts in this series

TEST LEAD GATOR TO GATOR 60"

Part	2nd Connector	Current Rating (Amps)	1st Connector	Voltage - Rated	Voltage - Rated	Material - Insulation	Cable Length	Cable Length	Wire Gauge	Temperature Range	Temperature Range	Contents [custom]	Contents
E-Z-Hook 684-60RED	Alligator Clip, Insulated	4 A	Alligator Clip, Insulated	5 kV	5 kV	Poly-Vinyl Chloride (PVC)	1524 mm	5 ft	18 AWG	105 °C	221 °F	1	Red
E-Z-Hook 684-60 R/B	Alligator Clip, Insulated	4 A	Alligator Clip, Insulated	5 kV	5 kV	Poly-Vinyl Chloride (PVC)	1524 mm	5 ft	18 AWG	105 °C	221 °F		2 Leads, Black and Red

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

60.0" (1524.00mm) Alligator Clip, Insulated To Alligator Clip, Insulated Test Lead 5000VDC (5kV) 1 Lead, Red
