Specification	F1238E48B-FHR

Air Flow	121 CFM
Approval Agency	CE, TUV, cUL, UL
Bearing Type	Ball
Current Rating	0.21 A
Fan Type	Tubeaxial
Features	Auto Restart
Noise	44 dB
RPM	3300 RPM
Size / Dimension Height	119 mm
Size / Dimension Length	119 mm
Size / Dimension Shape	Square
Static Pressure	0.33 in H2O
Termination	2 Wire Leads
Termination Leads Count	2 leads
Termination Type	Wire Leads
Voltage - Rated	48 VDC
Weight	0.097 lb
Width	38 mm

F1238 Series

Part	Current Rating	Fan Type	Approval Agency	Size / Dimension Height	Size / Dimension Shape	Size / Dimension Length	RPM	Bearing Type	Width	Voltage - Rated	Air Flow	Static Pressure	Noise	Termination Leads Count	Termination Type	Termination	Features	Weight	Termination Count
Mechatronics Fan Group F1238E48B-FHR	0.21 A	Tubeaxial	CE cUL TUV UL	119 mm	Square	119 mm	3300 RPM	Ball	38 mm	48 VDC	121 CFM	0.33 in H2O	44 dB	2 leads	Wire Leads	2 Wire Leads	Auto Restart	0.097 lb
Mechatronics Fan Group F1238M12B-FSR	360 mA	Tubeaxial	CE cUL TUV UL	119 mm	Square	119 mm	2300 RPM	Ball	38 mm	12 VAC	105 CFM	0.21 in H2O	38 dB	2 leads	Wire Leads	2 Wire Leads	Auto Restart Locked Rotor Protection	0.536 lb
Mechatronics Fan Group F1238E12B2-FHR-TTL	0.7 A	Tubeaxial	CE cUL TUV UL	119 mm	Square	119 mm	3300 RPM	Ball	38 mm	12 VAC	121 CFM	0.33 in H2O	44 dB	4 leads	Wire Leads	4 Wire Leads	Auto Restart Locked Rotor Sensor Speed Sensor (Tach)	0.59 lb
Mechatronics Fan Group F1238X24B-FHR	0.5 A	Tubeaxial	CE cUL TUV UL	119 mm	Square	119 mm	3600 RPM	Ball	38 mm	24 VAC	130 CFM	0.37 in H2O	47 dB	2 leads	Wire Leads	2 Wire Leads	Auto Restart	0.59 lb
Mechatronics Fan Group F1238H12BT-FHR	0.44 A	Tubeaxial	CE cUL TUV UL	119 mm	Square	119 mm	3000 RPM	Ball	38 mm	12 VAC	112 CFM	0.28 in H2O	41 dB			2 Terminals	Auto Restart	0.59 lb	2
Mechatronics Fan Group F1238H12B2-FS	0.44 A	Tubeaxial	CE cUL TUV UL	119 mm	Square	119 mm	2500 RPM	Ball	38 mm	12 VAC	115 CFM	0.25 in H2O	41 dB	3	Wire Leads	3 Wire Leads	Auto Restart Locked Rotor Sensor	0.536 lb
Mechatronics Fan Group F1238M48BT-FSR	120 mA	Tubeaxial	CE cUL TUV UL	119 mm	Square	119 mm	2300 RPM	Ball	38 mm	48 VDC	105 CFM	0.21 in H2O	38 dB			2 Terminals	Auto Restart Locked Rotor Protection	0.536 lb	2
Mechatronics Fan Group F1238X12BT-FSR	0.95 A	Tubeaxial	CE cUL TUV UL	119 mm	Square	119 mm	3100 RPM	Ball	38 mm	12 VAC	140 CFM	0.3 in H2O	45 dB			2 Terminals	Auto Restart Locked Rotor Protection	0.536 lb	2
Mechatronics Fan Group F1238E24B-FHR	0.35 A	Tubeaxial	CE cUL TUV UL	119 mm	Square	119 mm	3300 RPM	Ball	38 mm	24 VAC	121 CFM	0.33 in H2O	44 dB	2 leads	Wire Leads	2 Wire Leads	Auto Restart	0.59 lb
Mechatronics Fan Group F1238S12B1-FSR	0.18 A	Tubeaxial	CE cUL TUV UL	119 mm	Square	119 mm	1800 RPM	Ball	38 mm	12 VAC	83 CFM	0.14 in H2O	34 dB	3	Wire Leads	3 Wire Leads	Auto Restart Locked Rotor Protection Speed Sensor (Tach)	0.536 lb
