LTLMR4YVX3DA

Active

Diodes Inc

LED YELLOW DIFFUSED SMD

Search across all available documentation for this part.

Active

Diodes Inc

LED YELLOW DIFFUSED SMD

Technical Specifications

Parameters and characteristics for this part

Part	Height (Max) [Max] [z]	Viewing Angle	Voltage - Forward (Vf) (Typ)	Lens Transparency	Wavelength - Peak	Lens Style	Millicandela Rating	Color	Configuration	Mounting Type	Size / Dimension [x]	Size / Dimension [y]	Lens Size [diameter]	Wavelength - Dominant	Current - Test	Package / Case	Lens Color
Diodes Inc LTLMR4TCY2DA	7.4 mm	25 °	3.15 V	Diffused	505 nm	Round with Domed Top	19500 mcd	Cyan	Common Anode	Surface Mount	4.2 mm	4.2 mm	3.65 mm	507 nm	20 mA	3-SMD Gull Wing
Diodes Inc LTLMR4TG12DA	7.4 mm	25 °	3 V	Diffused	520 nm	Round with Domed Top	33000 mcd	Green	Common Anode	Surface Mount	4.2 mm	4.2 mm	3.65 mm	531 nm	20 mA	3-SMD Gull Wing	Green
Diodes Inc LTLMR4TGY13DA	7.4 mm	35 °	3 V	Diffused		Round with Domed Top	19500 mcd	Green	Common Anode	Surface Mount	4.2 mm	4.2 mm	4.2 mm	529 nm	20 mA	3-SMD Gull Wing
Diodes Inc LTLMR4YVX3DA	7.4 mm	35 °	2.1 V	Diffused	594 nm	Round with Domed Top	8750 mcd	Yellow	Common Anode	Surface Mount	4.2 mm	4.2 mm	3.65 mm	589.5 nm	20 mA	3-SMD Gull Wing	Yellow
Diodes Inc LTLMR4YW2DA	7.4 mm	25 °	2.1 V	Diffused	594 nm	Round with Domed Top	11600 mcd	Yellow	Common Anode	Surface Mount	4.2 mm	4.2 mm	4.2 mm	589.5 nm	20 mA	3-SMD Gull Wing	Yellow
Diodes Inc LTLMR4TBTV3DA	7.4 mm	35 °	3 V	Diffused	464 nm	Round with Domed Top	5200 mcd	Blue	Common Anode	Surface Mount	4.2 mm	4.2 mm	3.65 mm	470 nm	20 mA	3-SMD Gull Wing	Blue
Diodes Inc LTLMR4TCXZ3DA	7.4 mm	35 °	3.15 V	Diffused	505 nm	Round with Domed Top	15150 mcd	Cyan		Surface Mount	4.2 mm	4.2 mm	3.65 mm	507 nm	20 mA	3-SMD Gull Wing	Cyan

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Yellow 589.5nm LED Indication - Discrete 2.1V 3-SMD, Gull Wing
